Outdoor advertising machine series of products are using professional and unique ultra high brightness LED backlight modular heat dissipation module design, and the latest international outdoor technology, with air conditioning, air conditioning overall heat dissipation design, with the most simple technical design concept to achieve the most stable high-performance products. To achieve excellent optical display characteristics, good body thermal conductivity and ultra-high product reliability, whether in the hot and high temperature environment of strong sunlight direct exposure to the screen surface for a long time, or in the environment as low as -30°C, can meet the long-term stable work and display bright colors and clear images. It is the LCD with excellent brightness stability using LED backlight in similar products worldwide.
Features of outdoor waterproof digital signage products:
1、The liquid crystal panel and protective glass adopt a full bonding process.
2、The protective glass adopts full-tempered AR technology.
3、The shell heat dissipation adopts aluminum alloy gold heat sink.
4、Ultra-thin body, screen thickness of 45mm, overall thickness: 90mm.
5、Maximum brightness of 4000 nits.
6、Environmental brightness is automatically adjusted.
7.、Support horizontal and vertical video playback.
System | CPU | RK3288/RK3399 Windows i3/i5/i7 |
RAM | 2GB/4GB (optional), 4GB/8GB/16GB | |
Internal memory | 8GB/16GB, SSD128G/512GB/HDD500G/1TB | |
Operation system | Android 5.1/7.1/8.1/9.0, windows 7/8/10 | |
Display | Panel | 49" (Accept customization) |
Resolution | 1920*1080/3840*2160 optional | |
Contrast ratio | 1400:1 | |
Brightness | 2000-4000 cd/m2 | |
Aspect Ratio | 16:9 | |
Network | WiFi | 802.11 b/g/n_2.4G ( support 5G optional) |
Buletooth | Bluetooth 4.0 | |
Mobile network | Support 4G(optional) | |
Ethernet | 10M/100M/1000M Ethernet | |
Interface | USB | USB_OTG*1 |
RJ-45 | 10/100/1000M Ethernet port | |
Power adapter | 3.5mm stereo headphone output | |
Waterproof grade | IP65 | YES |
System Management | APK install | APK installer |
Root permission | Original Android system, open root permissions, product customization development | |
Remote control | Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended | |
OTA upgrade | Support OTA remote upgrade | |
Others | Recording | Support high-quality recording function (optional) |
Camera | 200W/500W(Optional) | |
OSD Language | Multi-language OSD Operation |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
