RisingLCD range of Slimline Passenger Information Displays are perfect for bus and train platforms. These digital signage displays are all with high brightness , With a great brightness rating of 700 nits( 1000nits, 2500nits, 3000nits, 4000nits are available) these display clearly delivers contents and attract public attention, which is the ultimate display for outdoor visibility.
RisingLCD 29 inch high brightness passenger information panel, 2560*1080 high resolution, 800 nits high brightness, 1000:1 contrast ratio, anti-glare surface treatment, 89/89/89/89 wide viewing angle, and these LCD panels are ideal to used to exhibit stop names, transport timetables, traffic message, announcements and other important notices as the passenger information display.
29 inch stretch high brightness passenger information LCD panel main features:
1. 2560x1080 Resolution, high resolution
2. 800 nits high brightness brightness
3. 1000:1 contrast ratio
4. Lower power consumption
5. High quality panel with 89/89/89/89 viewing angle.
Product technology
1. Our high brightness passenger information displays are equipped with original industrial-grade open cell from SAMSUNG, LG, AUO, LNNOLUX, BOE, TCL CSOT, etc., our own special designed advanced LED backlight will make the brightness more uniform, delicate colors, and vivid images.
2. Adopt aluminum alloy or sheet metal rim shell, surface anodization treatment or powder spraying treatment, cold-rolled steel plate back shell, active heat dissipation
Ultra strech LCD panel
This stretch passenger information display with ultra wide screen are best options among passenger information display, 29 inch wide size ensures that the screen remains visible easily, and making it easy for passengers to read important information and messages in the bus station, railway station and airport.
High brightness
1500 nits, high brightness ensures that the screen remains visible even in direct sunlight, making it easy for people to read important information and messages.
Passenger information display offer the passenger a full-service digital signage platform, we can produce and supply different sizes passenger information screen to meet you different request, such as concourse display, metro platform display, train information display.
RisingLCD range of Slimline Passenger Information Displays are perfect for bus and train platforms. These digital signage displays are all with high brightness , With a great brightness rating of 700 nits( 1000nits, 2500nits, 3000nits, 4000nits are available) these display clearly delivers contents and attract public attention, which is the ultimate display for outdoor visibility.
Diagonal size (inch) | Display Area (H*V/ mm) | Resolution | Brightness ( cd/m²) | View Angel | Contrast Ratio |
19.1 | 476.64×89.37 | 1920(RGB)×360 | 300-3000 | 89/89/89/89 | 1200:1 |
19.5 | 476.6*134 | 1920(RGB)x540 | 300-3000 cd/m² | 89/89/89/89 | 3000:1 |
21.2 | 529.416 × 99.265 | 1920(RGB)×360 | 300-3000 cd/m² | 89/89/89/89 | 1200:1 |
24 | 598×1128 | 1920(RGB)×360 | 300-3000 cd/m² | 89/89/89/89 | 1200:1 |
28 | 700×131 | 1920(RGB)×360 | 300-3000 cd/m² | 89/89/89/89 | 1200:1 |
33.8 | 825.6×232.2 | 2560(RGB)×720 | 300-3000 cd/m² | 89/89/89/89 | 1200:1 |
37.6 | 919.3 × 258.6 | 1920(RGB)×540 | 300-3000 cd/m² | 89/89/89/89 | 1000:1 |
43 | 1073.78 × 201.336 | 1920(RGB)×360 | 300-5500 cd/m² | 89/89/89/89 | 1200:1 |
47.6 | 1189.44×223.02 | 1920(RGB)×360 | 300-5500 cd/m² | 89/89/89/89 | 1200:1 |
48 | 1194.05 × 223.884 | 3840(RGB)×720 | 300-5500 cd/m² | 89/89/89/89 | 1000:1 |
48.5 | 1209.6×226.8 | 1920(RGB)×360 | 300-3000 cd/m² | 89/89/89/89 | 4000:1 |
49 | 1195.78×336.31 | 3840(RGB)×1080 | 300-5500 cd/m² | 89/89/89/89 | 3000:1 |
86 | 2158*337 | 3840(RGB) *600 | 300-5500 cd/m² | 89/89/89/89 | 1200:1 |
88 | 2158*607 | 3840(RGB)×1080 | 300-5500cd/m² | 89/89/89/89 | 1100:1 |
| Screen Diagonal | 29 inch |
| Brand | RisingLCD |
| Model No | RS290WW2-NE08 |
| Active Area | 672.768(W)×283.824(H) mm |
| Pixels | 2560(RGB)×1080, CSHD 96PPI |
| Physical Size | 693.6(W)×308.9(H) ×17(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 1000:1 |
| White Luminance ( Center ) | 800 cd/m2 (Typ.) [cd/m2 ] |
| Optical Response Time | 14 (Typ.)(G to G) |
| Nominal Input Voltage | 10.0 V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [g] | 3.11/3.265Kgs (Typ./Max.) |
| Interface Type | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Support Color | 16.7M 99% sRGB |
| Surface Treatment | Antiglare, Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | 0 ~50 °C |
| Storage (Non-Operating) | -20 ~ 60 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
