RS238HNX01A01-BJ is RisingLCD outdoor IP65 rated digital signage, with a full HD 1920*1080 resolution, and 16:9 aspect ration, 1500 nits high brightness, PCAP multi touch funciton.
Reliable Global Supplier of Outdoor IP65 Waterproof LCD Digital Displays
Durable screens built for all weather, delivering sharp visibility in rain, dust, or sunlight. Trusted worldwide for smart retail, transit hubs, and EV charging stations.
23.8-Inch Outdoor Waterproof LCD Display | 2500 Nits High Brightness, IP65 Certified, All-Weather Digital Signage for Small Businesses
Core Selling Points:
Sunlight Readability: 2500 nits ultra-bright panel ensures clear visibility even under direct sunlight.
Military-Grade Durability: IP65 waterproof & dustproof rating + -30°C to 60°C operating range, built for rain, snow, and desert heat.
Plug & Play: Pre-installed mounting brackets and VESA compatibility for fast installation.
Cost-Effective: Low power consumption (<50W) and anti-corrosion aluminum frame slash maintenance costs by 40%.
Target Scenarios:
1. Community Retail: Perfect for convenience store window displays, gas station price boards, and food truck menus.
2. Compact Public Spaces: Ideal for bus stop timetables, park info kiosks, and small outdoor ticket counters.
3. 24/7 Reliability: Runs non-stop at drive-thrus, pharmacy pick-up zones, and self-service kiosks.
4.Custom Ready: Support HDMI/VGA/DVI/USB/RJ45/DP system integration; adapts to any content (ads, menus, info boards).
Why Choose ours?
"Small screen, big impact!" – Designed for tight budgets and compact spaces, yet matches high-end displays in weatherproof performance. CE/FCC/RoHS certified, 3-year warranty, bulk order discounts available.
IK10 tempered glass with optical bonding provides the strongest protection
Having multiple national patent certificates
Model Name | RS238HNX01A01-BK |
Screen Size | 23.8" |
Display Area (mm) | 527.04(H) x 296.46(V) |
Brightness | 1500 cd/m2 |
Resolution | 1920x1080 |
Aspect Ratio | 16 : 9 |
Contrast Ratio | 1000 : 1 |
Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
Color Saturation (NTSC) | 67% |
Display Colors | 16.7M |
Response Time (Typical) | 14(Typ.)(Tr/Td) (ms) |
Input Interface | |
CPU | D6462 |
OS | Windows 10 |
RAM | 2G/4G |
Memory | 64G/128G/256/512 |
OSD Key | N/A |
Glass | 3MM Tempered Glass OCR |
Touch Type | PCAP |
Input Power | AC 100-240v |
Power Consumption | 50W |
Radiator System | Active heat dissipation without fan |
Dimensions (mm) | 558 x 351.5 x70.7mm |
Mounting | 100x100mm Screws metric M4 |
Weight (Net) | 10.7kg |
IP Grade | IP65 |
Operating Temperature | -0 ˚ C ~ 50 ˚ C |
Storage Temperature | -20 ˚ C ~ 60 ˚ C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
