RS238HNX01A01-BJ is RisingLCD outdoor IP65 rated digital signage, with a full HD 1920*1080 resolution, and 16:9 aspect ration, 1500 nits high brightness, PCAP multi touch funciton.
Industrial Outdoor waterproof LCD display for bus station information, size from medium size 32 inch to Large size 86 inch screen brightness from 1500 nits to 5000 nits, sunlight visible bus stop advertising display
Outdoor digital signage is fully customized with original and new A+ brand, widely used in shopping malls, streets, bus stops, gas stations, outdoor advertising areas, roadside rest stations and other places. It is integrated with an automatic cooling function when the outside temperature rises, and the heating module provides heating when starting in a frozen state.
Main Features:
Structure:
Slim and thin design, fanless cooling system, low noise
Waterproof, dust-proof, anti-corrosion, explosion-proof, anti-ultraviolet, anti-theft, anti-biological, elegant design, accept customization, Rated IP65, it can provide the highest level of protection of any outdoor display on the market.
Display:
High-definition, high brightness, intelligent photosensitive, full view angle, sunlight readable. high brightness for outside bus station display
Electronics:
Lightning protection, leakage protection, intelligent timing, intelligent temperature control system
Additional configuration
Support remote monitoring, touch interaction, smart bank card/ QR Code/ID Card recognition, smart print.
HNX01A01-BKHNX01A01-BK
Model Name | RS238HNX01A01-BK |
Screen Size | 23.8" |
Display Area (mm) | 527.04(H) x 296.46(V) |
Brightness | 1500 cd/m2 |
Resolution | 1920x1080 |
Aspect Ratio | 16 : 9 |
Contrast Ratio | 1000 : 1 |
Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
Color Saturation (NTSC) | 67% |
Display Colors | 16.7M |
Response Time (Typical) | 14(Typ.)(Tr/Td) (ms) |
Input Interface | |
CPU | D6462 |
OS | Windows 10 |
RAM | 2G/4G |
Memory | 64G/128G/256/512 |
OSD Key | N/A |
Glass | 3MM Tempered Glass OCR |
Touch Type | PCAP |
Input Power | AC 100-240v |
Power Consumption | 50W |
Radiator System | Active heat dissipation without fan |
Dimensions (mm) | 558 x 351.5 x70.7mm |
Mounting | 100x100mm Screws metric M4 |
Weight (Net) | 10.7kg |
IP Grade | IP65 |
Operating Temperature | -0 ˚ C ~ 50 ˚ C |
Storage Temperature | -20 ˚ C ~ 60 ˚ C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
