RisingLCD can offer waterproof LCD display with variety of size, resolutions and aspect ratios for your outdoor signage needs, for example, 21.5 inch, 32 inch, 48.5 inch, 49 inch, 55 inch, and 4:3 aspect ratio resolution, 5:4 aspect ratio resolution, 16:9 aspect ration resolution. These outdoor waterproof LCD display are used in auto racing, car wash facilities, mass transit, bus station park.
RS430LNX01A01 is a 43 inch LCD display from Risingstar, it was modified by another high waterproof low brightness LCD display in our product list: RS430LNX01P01, both of them has IP67 waterproof and 500-nits brightness, the only difference is we replace the Windows OS with Android OS, gives the display much open ability.
Out of the ordinary: Depends on the lowe birghtness, RS430LNX01A01 only need 51W for power consumption, so you do not need worry about the consumption if mounting it on the boat, more information please searching on our website: www.risinglcd.com
Size (inch) | 21.5 | 32 | 43 | 55 | 65 |
Model number | RS215MNX01D01 | RS320MNX01D01 | RS430LNX01A01 | RS550MNX01D01 | RS650MNX01D01 |
Brightness (cd/m2) | 1000 | 1500 | 500 | 2000 | 3000 |
Resolution (pixels) | 1920*1080 | 1920*1080 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 |
Power (Watt) | 51 | 265 | 300 | ||
Operating temperature | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ |
LCD panel: Risingstar has ability making our own design LCD panel, and we purchase A and A+ level Open-cell from LG, BOE, AUO and other famous liquid crystal glasses maker directly, this is the proof to make the high quality displays for each of our customers.
Hosuing: The classic Risingstar display has full metal shells with matte black coating, this allowed the display has strength to afford and protect the vulnerable electroinc components from possibly impacts.
Electronic: Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltages is the basic issue we should figure out for our customers, you do not need to worry about this; the possibly OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.
43-inch window facing display series:
RS430MNX01D01, lower brightness but full waterproof indoor display, special product for low light environment such like Museum/Aquarium...
RS430MNX03D01, semi-outdoor and super slim design, the most highest integrated display we ever made...
RS430HNX02D05, much thincker and heavier type, but lower consumption and unique outer shell, all these for "Mute"...
Model Name | RS430LNX01A01-BK |
Screen Size | 43" |
Display Area (mm) | 940.9(H) x 529.3(V) |
Brightness | 500 cd/m2 |
Resolution | 1920x1080 |
Aspect Ratio | 16 : 9 |
Contrast Ratio | 1200 : 1 |
Response Time (Typical) | 8 (Typ.)(Tr/Td) (ms) |
Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
Display Colors | 16.7M |
OS | Android 11 |
CPU | I5 |
RAM | |
HDD | 128G |
Glass | glass; Surface hardness ≧3H; |
Touch Type | N/A |
Input Power | AC100-240V |
Power Consumption | 51W |
Radiator System | N/A |
Input Interface | AC 1N USB*2 LAN*2 RS232*1 |
Dimensions (mm) | 1020 x 608.5 x 72mm |
Mounting | 400*400 |
Weight (Net) | 32.5Kg |
IP（Ingress Protection） | IP67 |
Operating Temperature | -20 ˚ C ~ 70 ˚ C |
Storage Temperature | -20 ˚ C ~ 70 ˚ C |
RS430LNX01A01 is a 43 inch LCD display from Risingstar, it was modified by another high waterproof low brightness LCD display in our product list: RS430LNX01P01, both of them has IP67 waterproof and 500-nits brightness, the only difference is we replace the Windows OS with Android OS, gives the display much open ability.
Out of the ordinary: Depends on the lowe birghtness, RS430LNX01A01 only need 51W for power consumption, so you do not need worry about the consumption if mounting it on the boat, more information please searching on our website: www.risinglcd.com
Size (inch) | 21.5 | 32 | 43 | 55 | 65 |
Model number | RS215MNX01D01 | RS320MNX01D01 | RS430LNX01A01 | RS550MNX01D01 | RS650MNX01D01 |
Brightness (cd/m2) | 1000 | 1500 | 500 | 2000 | 3000 |
Resolution (pixels) | 1920*1080 | 1920*1080 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 |
Power (Watt) | 51 | 265 | 300 | ||
Operating temperature | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ | 0 ~ 50℃ |
LCD panel: Risingstar has ability making our own design LCD panel, and we purchase A and A+ level Open-cell from LG, BOE, AUO and other famous liquid crystal glasses maker directly, this is the proof to make the high quality displays for each of our customers.
Hosuing: The classic Risingstar display has full metal shells with matte black coating, this allowed the display has strength to afford and protect the vulnerable electroinc components from possibly impacts.
Electronic: Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltages is the basic issue we should figure out for our customers, you do not need to worry about this; the possibly OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.
43-inch window facing display series:
RS430MNX01D01, lower brightness but full waterproof indoor display, special product for low light environment such like Museum/Aquarium...
RS430MNX03D01, semi-outdoor and super slim design, the most highest integrated display we ever made...
RS430HNX02D05, much thincker and heavier type, but lower consumption and unique outer shell, all these for "Mute"...
