Brand:
RisingStar
Model name:
RS121XCE-GE15
Screen size:
12.1"
Screen type:
Outdoor LCD Monitor
Resolution:
1024(RGB)×768
Brightness (cd/m²):
1500
RS121XCE-GE15 is a 12.1 inch LCD panel from RisingStar with the LCD open cell from AUO directly, combined with our own deisgn backlight and structure, this panel can reach 1500 nits with ELED structure and keep working through -20℃ to 60℃, these feature allowed this LC panel could be used in outdoor working environment such as the interface panel of the vending machine, charging/gas pile, etc.
This panel is a suitable choice for the customers who are the manufacturer either, but need a LCD screen can working with their own products with the high brightness and keep working in complicate environment inside their products.
| Panel Brand | RisingStar |
| Panel Item | RS121XCE-GE15 |
| Size | 12.1 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 1024(RGB)*768 |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 245.76*184.32(H*V)mm |
| Outline Size | 249*187.5(H*V)mm |
| Surface Treatment | AG (Haze 28%) Hard coating(3H) |
| Brightness | 1500 cd/m² |
| Constrast Ratio. | 1000：1(Typ.)(TM) |
| View Angle | 89/89/89/89(Min) |
| Best View on | Symmetry |
| Response Time | 25 ms |
| Display Color | 16.7M 72% NTSC |
| Backlight | WLED, 50K hours |
| Touch Screen | N/A |
| Panel Weight | TBD |
| Frame Rate | 60Hz |
| Signal Interface | LVDS 20 pins |
| Input Voltage | 3.3V(Typ.) |
| Working Temperature | -20 ~ 60℃ |
| Storage Temperature | -20 ~ 60℃ |
| Current State: | In Production |
