RisingLCD RS150ENT-GE10 is with a full HD 2k IPS 15 inch industrial lcd panel, high resolution 1024*768, and 4:3 aspect ration, the high bright LED backlight display provides over 1000nits of high brightness, and 1000:1 constrast ratio and 178 degree view angle, all that of features that making the LCD panel sunlight readable, it is ideal for the outdoor application.
These rugged LCD panels are rigorously tested to ensure compliance with various industry standards and are ideal for use in any high ambient light condition, and and will give you the intensity and brilliance your application requires.,
15 inch sunlight readable industrial TFT LCD panel
Main Features:
True Industrial Grade LCD Panel
Long-Life Advanced LED Backlight, over 50,000 Hours Half-Life
1000 nits (cd/m2) sunlight readable Brightness
Smart Brightness Control Exceptional Contrast for Improved Sunlight Readability
Wide Operational Temperature Range -20°C to 70°C (-22°F to 185°F)
Touch Screen Technologies Available (Optional)
RisingLCD can offer more sizes industrial LCD panel, high brightness from 700 nits to 5000 nits.
| Screen Diagonal | 15 inch |
| Brand | RisingLCD |
| Model No | RS150ENT-GE10 |
| Active Area | 304.128(W)×228.096(H) mm |
| Pixels | 1024(RGB)×768, XGA, 85PPI |
| Physical Size | 326.5(W)×253.5(H)×10(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 1000:1 |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Optical Response Time | 30 (Typ.)(Tr+Td) ms |
| Nominal Input Voltage | 3.3 V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [g] | 930g |
| Interface Type | 20 pins LVDS (1 ch, 8-bit) |
| Support Color | 16.7M , 72% NTSC |
| Surface Treatment | Hard coating (3H), |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | -20 ~70 °C |
| Storage (Non-Operating) | -20 ~ 70 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
