RisingLCD 13.3 inch open frame LCD monitor, it is with RisingLCD factory own design direct led back light that improve the brightness to 2000 nits that make the display can be read even in the directly sunlight,
Open frame display is one that has no enclosure or bezels confined to a bare metal chassis to which all internal components are bolted. The advantage of using this type of display in your application (whether it's a kiosk, keyboard or signage display) is that, as an integrator, you have the freedom to design a custom enclosure that fits your specifications and needs.
13.3 inch open frame LCD monitor main features:
High brightness 2000nits
Sunlight Readable
LED Backlight
Wide Viewing Angle of 178°(H), 178°(V)
Wide Operation Temperature (-0 ˚C~50˚C)
LCD Blacking Defect Free
Low Power Consumption
BL MTBF: 50,000 hours
Intelligent temperature control system, active heat dissipation
RisingLCD can offer the PWM, DC and auto light sensor brightness adjustment, and brightness can be achieve from 700 nits to 5000 nits, size from 10.1 inch to 110 inch, high brightness display are ideal for outdoor devices, such as window facing display, public transpartion information display, digital sigange, outdoor kiosk, etc.
Screen Size 13.3 "
Display Area (mm) 293.76(H) x 165.24(V)
Brightness 2000 cd/m 2
Resolution 3840x2160
Aspect Ratio 16 : 9
Contrast Ratio 1800 : 1
Pixel Pitch (mm) 0.0765(H) x 0.0765(V)
Viewing Angle 89/89/89/89 (Min.)(CR≥10)
Color Saturation (NTSC) 71%
Display Colors 16.7M
Response Time (Typical) 30 (Typ.)(Tr/Td) (ms)
Input Interface EARPHONE OUT*1 HDMI*2 DP*1 DC IN*1
OSD Key Power/Menu/Right/Left/Exit/Down/Up
Input Power DC12V~5A
Power Consumption 22W
Radiator System Automatic heat dissipation
Dimensions (mm) 313 x 189.5 x 40
Mounting 75x75mm Screws metric M4
Weight (Net): 1.8KGS
Operating Temperature -0 ˚ C ~ 50 ˚ C
Storage Temperature -10 ˚ C ~ 60 ˚ C
Ask a quote for the latest price and one of our team members will respond as soon as possible.
