A 21.5-inch LCD module with a-Si TFT-LCD technology with a brightness of 1000, which is readable in sunlight at all viewing angles.
Brand：
RisingStar
Model name：
RS215FHM-ND10
Screen type：
a-Si TFT-LCD,LCD module
Size：
21.5 inch
Contrast Ratio：
1000:1
Brightness：
1000cd/m2 or customized
Resolution ratio：
1920(RGB)×1080 FHD 102PPI
RS215FHM-ND10 is a 21.5 inch LCD module with a-si TFT-LCD technology. It is equipped with WLED backlight, the display resolution is 1920(RGB)×1080, the pixels are arranged in RGB vertical stripes, the display area is 476.64×268.11(H×V)mm, 500 brightness, adopts LVDS (2 ch, 8-bit) , 30 pins, terminal connection, operating temperature from -10°C to 50°C, storage temperature from -50°C to 60°C.
The model parameters of the same size are as follows.
| brand | RisingStar | Model name | RS215FHM-ND10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -10 to 50 °C Operation Temperature: -20 to 60 °C |
Q: who are we?
A:R-star originated from Shenzhen, China, We are a professional manufacturer of high-brightness LCD, we can provide from 10.1 to 120 inch highlight TFT LCD modules, In short, Rising has more than 5 years of high brightness backlight module technology experience, 8 years of large TFT module design, research and development, production capacity, 10 years of high-quality raw material supply chain.
Q: how can we guarantee quality?
A:Always final Inspection before shipment.
| brand | RisingStar | Model name | RS215FHM-ND10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1000cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -10 to 50°C Operation Temperature: -20 to 60 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
