RisingStar 37 inch high brightness stretch LCD bar provides 1920*540 ultra wide aspect ratios, 1500nits high brightness, can be clearly visible under direct sunlight, and give perfect visual performance in a wide public application, especially for the passenger information on the public transport scuh as train.metro station
RisingStar 37 inch stretched LCD displays are using the original factory open cell instead of the resizing or 'cut' LCD panels, whcih is the standard size, and reduces the risk of broken glass, micro cracks, and any light leakages.
Stretched bar LCD display is an innovative ultra-wide, sunlight readable LED backlight LCD display, it provides an LCD panel with specific rations for digital signage, public transportation, exhibition hall, department store, vending machine, POS and industrial applications, it is a high-quality full color video with energy-efficient.
RisingStar high brightness stretch bar LCD display is with super-wide aspect ratios as wide as 16:1 and in sizes ranging 19inch, 24inch, 21 inch, 28inch, 37 inch,43.8inch, 48.5 inch, 58.4 inch, (customization sizes as you like), and with customized backlight, the brightness can achieve 3000nits, or even higher (more brightness are option, 1000nits, 1500nits, 2500nits, 3500nits, 4500nits, 5500 nits, high brightness makes these screen can read even in the directly sunlight, ideal for passenger information display, transport timetables, traffic messages, announcements and other important communications.
| 37" RS370IVN-GD25 Outdoor Stretched Monitor | |
| Panel Brand | RisingStar |
| Panel Item | RS370IVN-GD25 |
| Size | 37 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 1920(RGB)*540 54PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 904.32*245.34(H*V)mm |
| Outline Size | 923.3*277.1*30.5(H*V*D)mm |
| Bezel Area | 907.5*257.5(H*V)mm |
| Surface Treatment | Antiglare (Haze 28%) , Hard Coating (3H) |
| Brightness | 2500cd/m² |
| Constrast Ratio. | 4000:1 |
| View Angle | 89/89/89/89(Min) |
| Display Model | AMVA3, Normally Black, transmissive Display |
| Best View on | Symmetry |
| Response Time | 5 (Typ.)(G to G) |
| Display Color | 16.7M/1.078 76% s RGB |
| Backlight | WLED, 70K hours, With LED Driver |
| Touch Screen | Without |
| Panel Weight | 4.59Kgs |
| Frame Rate | 60Hz |
| Signal Interface | LVDS (2ch, 8-bit), 51 pins connector |
| Input Voltage | 12v(Typ.) |
| Working Temperature | 0-+50 ﾟC |
| Storage Temperature | -20-+60 ﾟC |
| Current State: | In Production |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
