AUO P370IVN04.1 is 37-inch LCD-TFT display module with 1920x540 resolution (any view). The module is equipped with an Edge LED backlight, LED inverter, a MVA screen. The display characterizes with a brightness of 2500 cd/m², a static contrast ratio of 4000:1 and an ability to work in the industrial temperature range (0~50°C).
High brightness is a Main features of the product, it can work for a long time with wide range of temperatures, and could be read in the sunlight, and the long woking time ( Life ≥ 70K hours) so it will be applied in transportation and automotive industry, govement lines, bus station etc.
And due to using the matrix with IPS/MVA technology (or variants),display can be readable from any angle, no gray scale inversion effect.
Hot Tags: 37 inch a-si tft lcd module, China, factory, cheap, price, customized, quotation, window facing LCD, Outdoor Suspended Advertising Player, Smart LCD Advertising Player, transparent lcd panel, lcd splicing display P370IVN03.1, P370IVN02.2
| 37" AUO P370IVN04.1 Outdoor Stretched Monitor | |
| Panel Brand | AUO |
| Panel Item | P370IVN04.1 |
| Size | 37 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 1920(RGB)*540 54PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 904.32*245.34(H*V)mm |
| Outline Size | 923.3*277.1*30.5(H*V*D)mm |
| Bezel Area | 907.5*257.5(H*V)mm |
| Surface Treatment | Antiglare (Haze 28%) , Hard Coating (3H) |
| Brightness | 2500cd/m² |
| Constrast Ratio. | 4000:1 |
| View Angle | 89/89/89/89(Min) |
| Display Model | AMVA3, Normally Black, transmissive Display |
| Best View on | Symmetry |
| Response Time | 5 (Typ.)(G to G) |
| Display Color | 16.7M/1.078 76% s RGB |
| Backlight | WLED, 70K hours, With LED Driver |
| Touch Screen | Without |
| Panel Weight | 4.59Kgs |
| Frame Rate | 60Hz |
| Signal Interface | LVDS (2ch, 8-bit), 51 pins connector |
| Input Voltage | 12v(Typ.) |
| Working Temperature | 0-+50 ﾟC |
| Storage Temperature | -20-+60 ﾟC |
| Current State: | In Production |
